Universal Robot Core Training

Universal Robot Core Training

KEY TAKE-AWAYS FROM THIS COURSE

  • Manage the robot safely understanding safety concepts

  • Build and optimize programs for several typical applications such as pick & place, palletizing, polishing or dispensing

  • Connect and handle peripheral equipment, such as sensors, grippers or conveyor belts

  • Know the online tools and resources available to help with application programming

COURSE DESCRIPTION

After the 2-day course, you will have hands-on experience with a UR robot. You will have programmed the robot several times to perform common tasks, including the operation of common peripherals (conveyors, sensors, grippers). You will be able to optimize a pick and place flow, perform palletization, understand safety concepts, and know the additional resources available to them both online and through other training courses. You will be ready to return to your own robot and create pick and place, palletization, and other common application programs on your own.

Please note that you must have completed the Online Core Training to be able to sign up for the In-class Core Training.

PRICE

950 GBP plus VAT per person

LOCATION

Applied Automation X-STK
Neptune Point 2, Vanguard Way
Ocean Park
Cardiff
CF24 5PG
United Kingdom

training@x-stk.com
+442920 494551



COURSE CURRICULUM

Module 1: Pick-and-place Application

  • Moving the robot by using the “Move” tab

  • Knowledge about the I/O Connections and how to set up

  • How to setup the TCP

  • How to setup a Home Position

  • Basic Knowledge about URCaps

  • Apply skills acquired in the online training to an actual robot

    • Programming a Pick-and-Place application

Module 2: Safety settings

  • Configuration and using the available safety settings

    • Robot Limits

    • Joint Limits

    • Safety Planes

    • Tool position

    • Direction

    • Configurable Inputs/Outputs

    • Safe Home

Module 3: Optimize a pick-and-place application

  • Basic Knowledge about singularities

  • The different movement types and how to use them

    • MoveJ

    • MoveL

    • MoveP

    • MoveC

  • How to configure a blend radius

  • Configuration of speed and acceleration of movements and individual waypoints

  • How to use Time to investigate the cycle time

  • Creation of a clear program structure

Module 4: Easy Start up

  • Configuration of a default program that starts automatically when the robot powers up

    • Programming a Before Start Sequence

    • Howe to program relative waypoints

    • How to set up remote control

    • Set up a default program

Module 5: Program Flow

  • Configuration and use if-else commands

  • Basic knowledge about variables

  • How to program a subprogram

Module 6: Palletizing

  • Configuration and usage of palletizing template

Module 7: Force Control (simple)

  • Knowledge about the force control (simple)

  • Knowledge about how to program Threads

  • Configuration of the Force control (simple)

  • Using the data of the integrated force and torque sensor in the program

Module 8: Process application and operator selection

  • Configuration of the TCP, orientation and payload using the available wizards

  • Programming Loop statements

  • Prompt Operator for variable input

  • Configuration and usage of switch-case commands

  • Catching and handling an invalid entry

Module 9: Flexible redeployment

  • How to create a coordinate system (Plane)

  • How to program relative to a coordinate system

Module 10: Implementation plan

  • A structured method (ten steps) to identify and evaluate the complexity of the automation capabilities in your cobot

Module 11: Online resources

  • Free software updates

  • Use, service and script manuals

  • CAD data of the robot, teach pendant and controller

  • Offline simulator
